Cadence Announces Industry’s First Verification IP for USB4

March 15 2019, 00:45
Cadence Design Systems announced the availability of the industry’s first Verification IP (VIP) in support of the recently announced USB4 standard. The Cadence VIP for USB4 enables engineers to develop standard-compliant system-on-chip (SoC) designs, completing functional verification of the design with less effort and greater assurance that the SoC will operate as expected, enabling early adoption of the next-generation USB standard protocol.


“Cadence is an active member of the USB Implementers Forum (USB-IF) and supports the expansion of the USB ecosystem by providing the VIP and tools for developers to design to the newest USB standards,” says Jeff Ravencraft, USB-IF President and COO. “Support from member companies like Cadence helps reduce the barriers to adoption of new USB protocols and enables innovative products from new industries to enter the market.”

The USB Promoter Group announced the pending release of the USB4 specification, based on Intel’s Thunderbolt protocol. This enhances the transfer of both video and data, while doubling total available throughput to 40Gbps. Cadence developed the new USB4 VIP based on more than a year of collaborative work with early adopters of this new specification. The collaboration with early adopters has led to the availability of a proven and mature verification IP that reduces design risks and shortens the implementation of the new standard. Additionally, the Cadence VIP for USB4 includes TripleCheck technology, which provides users with a verification plan that is linked to the specification and a comprehensive test suite to ensure compliance with the USB4 specification.


“Cadence has supported the development of the new USB4 standard through our participation in the standards committee, and our work with early adopters enabled us to provide a solid and comprehensive verification solution for this emerging protocol,” says Paul Cunningham, corporate vice president and general manager of the System & Verification Group at Cadence. “By offering the first-to-market VIP for USB4 as part of the Cadence Verification Suite, we’re enabling early adopters to ensure their advanced designs for mobile, consumer and display applications comply with the specification while achieving IP verification closure.”

“Cadence’s development of verification solutions for USB4 is a key step forward for the development of compliant designs and ensuring the continued growth of the Thunderbolt ecosystem based on USB open standards,” adds Jason Ziller, General Manager of Client Connectivity Division at Intel.

“Our team has successfully utilized the Cadence VIP for multiple standards, including for the DisplayPort standard and previous versions of the USB specification,” says Anant Singh, VP of Engineering at Kandou Bus. “The Cadence solution for USB4 is critical to our development of industry-leading products to support the need for faster data speeds for high-performance applications.”

Cadence VIP for USB4 is part of the Cadence Verification Suite and supports the company’s System Design Enablement strategy, which enables system and semiconductor companies to create complete, differentiated end products more efficiently. The Verification Suite is comprised of best-in-class core engines, verification fabric technologies and solutions that increase design quality across a wide variety of applications and vertical segments, providing the best verification throughput.
The Cadence Verification IP (VIP) for USB4 provides a highly capable verification solution for the USB4 protocol incorporating bus functional model (BFM) and integrated protocol checkers and coverage, according to the next-generation USB protocol architecture of USB4 specification. The VIP for USB4 enables multiple simultaneous data and display protocols and supports them to share the bandwidth over the bus, including the two-lane operation and up to 40Gbps speed. The VIP for USB4 is compatible with the industry-standard Universal Verification Methodology (UVM) and runs on all leading simulators.

The USB4 protocol features details are currently restricted to the members of the USB4 Working Group. For more information on Cadence VIP for USB4, please visit www.cadence.com/go/usb4vip
