Pascal Sets New Bar for Power Density in Pro Audio Class-D with L-PRO Series Amplifier Modules

September 4 2018, 06:00
The Summer in Denmark was apparently a busy season and Pascal Audio has been working on very interesting new amplifier modules. The company just releases the new L-PRO2 series amp modules, which provide 50% more power from the same form factor as S-PRO series. As the company details, the new L-PRO2 series represents a new standard in power density for Class-D power amplification, as the world’s smallest 1500 W RMS amp module.

The L-PRO2 series inherits the ‘highest power density’ title from the S-PRO series module with which it shares a common form factor. Heralded as the world’s smallest 1000 W amplifier module when it was launched in 2012, the S-PRO retains that distinction and is now joined by the world’s smallest 1500 W amplifier module.

An ultra-compact power platform for 2-way and subwoofer applications, featuring extreme dynamic power ratings and integrated power supply with PFC, L-PRO2 is optimally designed for integration within high power sound touring and fixed venue PA and line array systems, and large subs. Three variants address specific applications; the L-PRO2 (1200 W + 400 W RMS) and L-PRO2HP (high power – 1500 W + 800 W RMS ) feature asymmetrical power configurations, with feature sets and a form factor uniquely optimized as a dedicated power solution for self-powered 2-way loudspeakers, and the symmetrical output channels of the L-PRO2S (1500 W RMS in BTL mode) optimized for use in large scale sub woofers.

Exceptionally high voltage rails combined with an ability to drive a low (4 Ohm) impedance load, provide a massive power headroom. As a result, the LF-channel of the L-PRO2HP and the L-PRO2S (in BTL mode) deliver an output voltage of 160 V peak, yielding a dynamic headroom of more than 2 dB and a peak SPL rating equivalent to a conventional 2500 W amplifier.

Using Pascal’s proprietary UMAC Class-D technology, the modules deliver superior sonic performance and quality in a pro audio optimized amplifier, including best–in-class signal-to-noise, distortion and dynamic range specifications.

All modules are equipped with comprehensive protection features and designed on an ‘audio-at-all-times’ principle, rendering them fully self-protecting. Like Pascal's S, T and U-PRO series modules, the L-PRO2 series boasts the best system efficiency, minimizing requirements for heat sinks and cooling, and contributing to the amplifiers' long-term reliability.

The L-PRO2 series also supports Pascal’s plug-and-play interconnect, that makes the complete range of 26-pin power amplifier modules inter-connectable to a single front-end I/O / DSP board design. A single front-end module can thus be used in multiple self-powered loudspeaker design configurations, reducing the required engineering work across multiple product design projects.

Energy Star Compliant auxiliary power outputs, readouts and control signals are available to feed integrated DSP or analogue I/O boards. Advanced real-time readouts of protect/mute, temperature and clip signals are accessible for DSP and network control implementations, and I/O stages.

The UREC PFC power supply technology enables universal AC mains operation, automatically adaptive to any mains voltage between 100 V and 240 V, allowing for the propriety high efficiency, compact power supply to deliver regulated power anywhere in the world.
Peter Frentz with the new L-PRO2 next to the similar sized S-PRO2.

“The L-PRO2 series completes our portfolio of front-end compatible amplifier modules optimized for pro audio self powered speakers, providing our clients with unique project portfolio benefits and cost savings. With new, even higher, power ratings, the L-PRO2 keeps us at the forefront of achievable levels of power density in amplifier modules,” says Peter Frentz, Senior VP of Business Development, speaking on the launch of L-PRO2 series.

All modules are now available, except for the L-PRO2HP, which is scheduled to commence production in Q4 2018. Pascal provides a complete Solutions & Applications Overview for Self-powered applications with the L-PRO2 series in its recently renovated website.
