With all the semiconductor focusing their attention on USB Type-C solutions at Computex 2017, Diodes introduced a critical solution for USB Type-C implementation in all sorts of devices. Specifically, the DPS1133 protects the VBUS lines to and from USB Type-C connectors, meets the fast role swap (FRS) timing criteria defined by the latest Release 3.0 Power Delivery Specification, and supports all the allowed USB-C port operational modes: downstream facing (DFP), upstream facing (UFP), and dual-role (DRP). Designed to operate between 4.5V and 24V, the DPS1133 can either act to provision or consume power at up to 3.5A through a USB Type-C connector, automatically protecting and recovering from fault conditions like over-voltage, over-current, short-circuit, reverse-voltage, and over-temperature, without the intervention of a system controller.
The low on-state resistance of the DPS1133 power switch (typically ≤30mΩ) enables the 3.5A maximum continuous current and helps minimize power dissipation, while the thermally efficient QFN4040-17 package ensures a sufficiently low surface temperature during operation. Usability is enhanced through the ability to use external resistors to adjust many device parameters, such as voltage and current limits, and ramp times. Control pins also allow the input and output ports to be discharged through an internal resistor.
