Test Bench: Precision Devices PD.CD2N 1.4” Titanium Diaphragm Compression Driver

In this edition of Test Bench, I characterized a 1.4” titanium diaphragm compression driver from Precision Devices. The new driver from this prestigious UK Pro Sound OEM manufacturer is part of a seven model lineup of high-performance neodymium compression drivers. The PD.CD2N has a 50.8 mm (2”) throat diameter, with a radial neodymium magnet motor structure, an aluminum three-slot phase plug, and nominal 105 W (AES) rated power handling. This article was originally published in Voice Coil, February 2018.

For this month's Test Bench, Dickason characterizes a new 12” coaxial pro audio driver from B&C Speakers, a design typically applied in stage monitors, studio monitors, or distributed audio in large venues. B&C Speakers 12CXN88 is unique in that it uses a single neodymium magnet assembly for both the 12” woofer and the 1.3” throat exit compression driver. This article was originally published in Voice Coil, January 2018.

The driver for this month’s Test Bench explication comes from the UK. Volt sent the 12” RV3143 Studio Monitor woofer, which is probably the most uniquely designed woofer to come across my desk in a while — there is no frame on the back side of the driver! The Volt Radial Technology consists of a front-mounted eight-spoke proprietary cast aluminum frame that is mechanically coupled to both the back plate and to the top of the pole structure/phase plug, in contrast to a normal rear frame that is only coupled to the motor front plate. This article was originally published in Voice Coil, December 2017.

The driver for this month’s Test Bench explication came from a German OEM driver manufacturer and is from Eton’s home audio Orchestra line of drivers. I asked Eton to send a model from this line, the 4-512/C8/25 RP, mostly because of the unique cone. All of the cones in the Orchestra line are serrated paper cones, which is somewhat reminiscent of the orange sliced paper cones in the Scan-Speak Revelator line. This article was originally published in Voice Coil, December 2017.

Beginning with the January 2018 issue of Voice Coil magazine, Vance DIckason implemented the Loudsoft FINE R+D analyzer into the Test Bench measurement protocol. This article provides details about the features in FINE R+D FINE R+D, a Fast Fourier Transform (FFT) analyzer packaged in a 1u rack, which is used with the recommended G.R.A.S. 0.25” Type 46BE microphone capsule and preamplifier body. This article was originally published in Voice Coil, December 2017.

Following the review of the Peerless by Tymphany PLS 2” PLS-50N25AL01-08 neodymium motor full range, in this edition of Test Bench I reviewed the 2.5" PLS-65F25AL01-08 ferrite motor full-range model. This 2.5" 8 ohm full-range member of the PLS family, the Peerless PLS-65F25AL01-08, has some differences. Unlike the PLS-50N plastic frame, the PLS-65F is built on a proprietary stamped steel frame that is fully vented below the spider mounting shelf with four 24 mm × 4 mm cutouts for enhanced cooling. This article was originally published in Voice Coil, November 2017.

The 2” to 2.5” diameter full-range drivers are unquestionably one of the most used transducers in consumer electronics. I asked the folks at Tymphany to send a couple of transducers from their Peerless by Tymphany PLS line of full-range 2” to 3” drivers. I specifically asked for the 2” PLS-50N25AL01-08 neodymium motor full range (reviewed here) as well as the 2.5” PLS-65F25AL01-08 ferrite motor full-range (reviewed separately). This article was originally published in Voice Coil, November 2017.

This Test Bench article examines the CQQ76 ribbon tweeter from BoZhen New Audio Lab. The original device BoZhen sent to Voice Coil in 2013, the CQ76 ribbon tweeter, was portrayed in the company literature as a unique (patent number ZL200820128865.6) ribbon tweeter design. “CQ” is an acronym in Chinese pinyin “Chuan-dao-pian Qu-dong,” which in English means “ribbon loudspeaker based on slice-conducted technology.” This article was originally published in Voice Coil, October 2017.

For this month’s Test Bench article, I examined the 745NEOBe, a pro sound 1.4” beryllium compression driver from Radian Audio Engineering. Radian Audio was founded in 1988 by its president, Dr. Richard Kontrimas, however, Kontrimas has since retired and the company is under new ownership, based in Orange, CA. With more than two decades of success under its belt, Radian Audio is now entering its third decade as a pro sound manufacturer. This article was originally published in Voice Coil, October 2017.

In this Test Bench, I examined the 28W/4878T00, a new 10” (28 cm) subwoofer from high-end OEM Danish driver manufacturer Scan- Speak. Scan-Speak’s 28W/4878T00 has a well-chosen feature set that includes a proprietary cast seven-spoke cast-aluminum frame that has minimal reflection surfaces and is completely open below the spider mounting shelf. Other features include a stiff, lightweight paper sandwich cone—further stiffened by a 3.25” convex coated woven fiber dust cap. This article was originally published in Voice Coil, September 2017.
